FRP Cable Trays
Our cable support systems are available in two types- Ladder cable tray and perforated cable tray. Our FRP cable support systems are ideal for locations where the metallic systems get easily corroded (Iron forms rusty layer and Aluminium makes white or silver greyish patina). GRP cable ladders and GRP FRP cable trays are made on fully automated heavy duty plant. Our cable trays meet stringent Fire retardant requirements. These are good replacement of those cable trays that easily get corrode, spread heat and erode.
Features:-
• Corrosion Resistant (Excellent Environment Resistant)
• Rigid & Structurally Strong
• High Impact strength
• Light weight
• Non conductive (Electrical & Thermal)
• Non Sparking
• Chemical Resistance
• Non Magnetic
• Resistance to cracking
• U.V Stabilized
• No water absorption.
Perforated Cable Tray
| Range | Load Range: | |||
|---|---|---|---|---|
| Width(mm) | Height(mm) | Width(mm) | Span (mm) | UDL kg/m |
| 50 | 25 | 50 | 1000 | 10 |
| 75 | 30 | 75 | 1000 | 15 |
| 75 | 50 | 100 | 1000 | 20 |
| 100 | 30 | 150 | 1000 | 30 |
| 100 | 50 | 200 | 1000 | 45 |
| 150 | 30 | |||
| 150 | 50 | |||
| 200 | 50 | |||
| 300 | 50 | |||
Ladder Type Cable Tray
| Load Range: | ||
|---|---|---|
| Side Runner (mm) | Width (mm) | UDL kg/m |
| 50/75/100/150 | 750 | 120 |
| 50/75/100/150 | 600 | 90 |
| 50/75/100/150 | 450 | 75 |
| 50/75/100/150 | 300 | 60 |
| 50/75/100/150 | 150 | 30 |
| 50/75/100/150 | 100 | 20 |
| Range | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Std. width (mm) [W] | 150 | 200 | 300 | 450 | 600 | 750 | 900 | 1000 | 1200 |
| Std. height (mm) [H] | 50 | 75 | 100 | 150 | |||||
| Std. length (mm) | 2500 | 3000 |
Discription
| Standard Product | Flame Retardent Product | |
|---|---|---|
| Material | Polyester Resin (Isopthalic) with UV Stabilizer Glass Content:- 60 -65 % | Vinylester FR Resin with UV Stabilizer Glass Content:- 60 -65 % |
| Fire Retardency | UL94 V1 ASTM E84 BS 476 Part 7, Class II ASTM D-2863 |
UL94 V0 ASTM E84 BS 476 Part 7, Class I ASTM D-2863 |
| Length | 3-5 mtrs | 3-6 mtrs |
| Width | 150-1000 mm | 150-1000 mm |
| Rung Construction | GRP Square Tubes | GRP Square Tubes |
| Rung Spacing | 300 mm | 300 mm or 500 mm |
| Coupler Plates | FRP Coupler Plates with SS bolts | FRP Coupler Plates with SS bolts |
| Radius of Bend | 300 mm | 300 mm/600 mm/900 mm |
| Angle of Bends | 90o , 45o | 90o , 45o |
| Electrostatic | Static | Antistatic |
